316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube

Brand Name : TOBO

Certification : ISO/PED/TUV/SGS/LR/BV

Place of Origin : China

MOQ : 1pcs

Price : Depending on quantity

Payment Terms : L/C, T/T, Western Union,

Supply Ability : 300000pcs per month

Delivery Time : 25-30 days depending on quantity

Packaging Details : Standard export sea-worthy packing

Standard : JIS

Application : Pharmaceutical and chemical fluid equipment

Processing Service : Bending, Welding, Decoiling, Punching, Cutting, Mouldin

Material : SUS304/316L

another name : stainless steel pipes

Model Number : 1/2"-12"

Invoicing : by actual weight

suitable for : Pharmaceutical and chemical fluid equipment

Contact Now

316L 304 seamless stainless steel pipe 300 Series Austenitic Stainless Steel Pipe Seamless stainless steel tube

Product Description

Sanitary Tubing for Food, Beverage & Dairy Process Lines Tp316L Stainless Steel Seamless Pipe

Description & Name: AISI316L SUS316L Tp316L Stainless Steel Seamless Pipe
Standard:
ASTM A213, A269, A312, A511, A789, A790, A376, EN 10216-5, EN 10297,DIN 17456, DIN 17458,JISG3459, JIS GS3463, GS3467, JIS G3448,
GOST 9940, GOST 9941,
Material:TP316/316L/316H, 304/304L/304H, 321/321H, 317/317L, 347/347H, 309S, 310S, 2205, 2507, 904L (1.4301, 1.4306, 1.4948,
1.4401, 1.4404, 1.4571, 1.4541, 1.4833, 1.4878, 1.4550, 1.4462, 1.4438, 1.4845)
Nominal Dia: 1/2 "to 32" NB for seamless pipe
Schedules: 5S, 10S, 40S, 80S, 10, 20, 30...120, 140, 160, XXS
All dimensions are in accordance with ANSI B36.19 and ANSI B36.10
Size Range for tubing: OD:1/4" (6.25mm) to 8" (203mm), WT 0.02" (0.5mm) to 0.5"(12mm)
Length:
30 m(Max) or as your requirement
Process:
Cold drawn, Cold rolled, Precision Rolled for Seamless Pipe or Tube
Finish: Annealed & pickled, bright annealing, polished
Ends: Beveled or plain end, square cut, burr free ,Plastic Cap at Both end
Packing: Bare packing/bundle packing with woven bag/wooden or steel frame crate packing/plastic cap protection at the both sides
of tubes and suitably protected for sea-worthly delivery or as requested.
Inspection and Test Procedure
1
100% PMI,Spectro Chemical Aanlysis Test for Raw Material
2
100% Dimension & Visual Examination
3
Mechanical Properties Test Include Tension Test,Flaring Test (For Seamless tube/pipe)/ Flange Test (For Welded Pipe & Tube), Hardness Test ,Reversed Flattening Test
4
100% Hydrostatic Test or 100% NON-DESTRUCTIVE Test (ET or UT)
5
Radiographic Test for Welded Pipe (shall be accordance with specification,or shall be as agreed upon between the purchaser and vendor)
6
Straightness Test (optional)
7
Roughness Test (optional)
8
ntergranular Corrosion Test(optional)
9
Impact Test (optional)
10
Grain Size Determinations (optional)
NOTES : ALL THE TESTS AND INSPECTION RESULT NEED TO BE SHOWED IN REPORTS ACCORDING TO STANDARD AND SPECIFICATION.
Size (Tube OD)
Part Number
Dimensions
304
316L
Wall Thickness
ID
Gauge
1/2"
A270P-304050
A270P-316050
0.065
0.370
16
3/4"
A270P-304075
A270P-316075
0.065
0.620
16
1"
A270P-304100
A270P-316100
0.065
0.870
16
1-1/2"
A270P-304150
A270P-316150
0.065
1.37
16
2
A270P-304200
A270P-316200
0.065
1.87
16
2-1/2"
A270P-304250
A270P-316250
0.065
2.37
16
3
A270P-304300
A270P-316300
0.065
2.87
16
4
A270P-304400
A270P-316400
0.083
3.834
14
Number of Tube Sticks Per Case
Size (Tube OD)
Piece Count
Total Footage
1"
15
300"
1-1/2"
15
300"
2"
15
300"
2-1/2"
15
300"
3"
10
200"
4"
5
100"
Additional Tube Specifications
Size (Tube OD)
Dimensions
Weight per Foot (lbs)
Burst Pressure (PSI)
Wall Thickness
Gauge
1/2"
0.065
16
0.30
10,833
3/4"
0.065
16
0.48
8,666
1"
0.065
16
0.66
9,750
1-1/2"
0.065
16
1.00
6,503
2"
0.065
16
1.35
4,875
2-1/2"
0.065
16
1.70
3,900
3"
0.065
16
2.05
3,248
4"
0.083
14
3.50
2,730
6"
0.109
14
5.29
1,820
Tube Tolerances
Part Number
O.D.
Wall
OD Tolerance
Wall Tolerance
Ovality Tolerance
Box Qty.
ASTM Standards
00507
0.5
0.065
+.002/-.008
+/-.008
*
300
A213/A270
00757
0.75
0.065
+.002/-.008
+/-.008
*
300
A213/A270
01007
1
0.065
+.002/-.008
+/-.008
*
300
A249/A269/A270
01507
1.5
0.065
+.002/-.008
+/-.008
*
300
A249/A269/A270
02007
2
0.065
+.002/-.011
+/-.008
*
300
A249/A269/A270
02507
2.5
0.065
+.002/-.011
+/-.008
*
300
A249/A269/A270
03007
3
0.065
+.003/-.012
+/-.008
*
200
A249/A269/A270
04007
4
0.083
+.003/-.015
+/-.010
*
100
A249/A269/A270
06007
6
0.109
+.030/-.030
+/-.010
*
20
A249/A269/A270
Details Images
Shape Round, square, rectangular
Material 201,202,303, 303Cu,304,304L,316,316L,310S,316Ti,321,430,904L,ETC
Production Standards ASTM A270, ASTM A269, ASTM A249, ASTM A778, ASTM A789, DIN 11850, EN 10357, EN 10217-7 and so on.
Usage Food processing industry, boiler, heat exchanger bundle, condenser, evaporator, chemical industry, oil and gas industry and so on.
Size

Normal size:

Outer diameter = 12.7-600mm;

Thickness = 0.8-20 mm;

Length = 6 -12m.

Or as customer' s request.
Our Service Free samples and OEM service are offered.

316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube

316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube

316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube

Chemical Composition about stainless steel

316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube

FAQ

Q: Does this tubing come with triclamp ends to be coupled together?
A: This particular tubing comes without tri-clamp ends standard. We can always weld tri-clamp ferrules to the end of tubes for any specific length you need. These products are referred to as tri-clamp spool assemblies. If you need a specific length, please
contact us.
Q: Are you able to cut tubing to lengths that don't require freight shipping? Say 5' lengths for example.?
A:Yes, we are able to cut down to other sizes. UPS Ground is able to ship up to 7' without the tubing being considered "oversized".We do charge a cutting fee for this service, however. Please contact us for a quote.
Q:How much does 1 stick of 4" tube weigh?
A: One 20' Stick of 4" Sanitary Tubing weighs approximately 75 pounds.
Q:You list gauge of this tubing at 16, but the wall thickness at 0.065". Isn't 16 gauge 0.0625"?
A: The wall thickness and gauges are all displayed in the table below. Please contact us if you have any other questions.
Q: Do you sell tubing in anything less than cases? I need to order just over 400 feet but don't want to pay for two cases as this is More than I need.
A: We do sell tubing on an individual basis however there is a $50 "broken box" fee applied to any order less than an entire case.Since we don't offer a way to order individual tube pieces online please call us to place an order over the phone.
Q: Do this product ship via freight?
A: Yes, our tubing comes in standard 20 foot lengths and will need to ship via freight. I'd also like to mention that there is a broken box charge meaning that if you do not order an entire box of tubing you will be charge additional fees as such. For more information please contact us. Thanks.
Company Profile
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
316L 304 Seamless Stainless Steel Pipe 300 Series Austenitic Stainless Steel Pipe Seamless Stainless Steel Tube
